Дънна платка ASUS ROG STRIX B760-I GAMING WIFI, B760, LGA1700, DDR5, PCIe 5.0, 4x SATA 6Gb/s, 2x M.2, Wi-Fi 6E, Bluetooth v5.3, HDMI, DP,8 Mini-ITX

SKU: ROG STRIX B760-I GAMING WIFI / 90MB1D90-M1EAY0

ID: #36717

Цена: 502,00 лв.

Цената е с вкл. ДДС

Характеристики

Поддържани процесори: Supports 13th Gen & 12th Gen Intel® Core™ Processors (LGA1700)

CPU Socket: Intel LGA1700

Чипсет: Intel B760

Максимален капацитет RAM памет: 96 GB

Памет, слотове: 2

Поддържана памет: DDR5

M.2 слот: 2 x M.2 slots / 4 x SATA 6Gb/s ports

Поддръжка на RAID: SATA / RAID 0, 1, 5, 10

Graphics технология: Няма

Вграден Bluetooth: Bluetooth V5.3

Мрежа: 1 x 10/100/1000 Mbps (RJ-45)

Wi-Fi Mодул: Да

Безжична мрежа: 802.11ax Wi-Fi 6E

HDMI: 1

DisplayPort: 1

Форм фактор: Mini ITX

Гаранция (месеца): 36

Бърза Поръчка

Съгласявам се с общите условия и обработка на личните ми данни.

Добави за сравнение

Описание

ASUS ROG STRIX B760-I GAMING WIFI LGA 1700 2xDDR5 Mini ITX 4xSATA MB 1xHDMI 2.1 1xDP 1.4 2xM.2


Manufacturer	ASUS
Manufacturer Part No	90MB1D90-M1EAY0

Marketing Description
Let your rig run wild with the ROG Strix B760-I, a feisty foundation for your next SFF build. Boasting hyperfast DDR5 memory, low-latency Wi-Fi 6E networking, and a future-ready PCIe 5.0 slot, it sets you up for savage speeds, all while giving you incredible 13th Gen support thanks to its powerful VRM and thermal solution.
Product Features
All-round performance Bulking up where it counts, the ROG Strix B760-I bears an octet of power stages mounted with a hefty cooling array to give you all the fury of Raptor Lake. To pack on the FPS, the PCIe 5.0 slot is primed for the mightiest graphics card you can fit your chassis, and the memory slots can handle dizzying DDR5 speeds. Leading connectivity Massive throughput flows through the ROG Strix B760-I via advanced networking adapters and high-bandwidth USB connectors, allowing you to rip through games with no interference, and crystal-clear on-board audio keeps you immersed in the experience. Play in style The shrouds and PCB of the Strix B760-I pair well with most products from the diverse ROG ecosystem, all while making your build distinct with a dash of polychromatic contrast. Software utilities Customize your rig through a suite of intuitive software and firmware utilities that let you maximize performance and tweak your experience to your liking.
General
Product Type	Motherboard - mini ITX
Chipset Type	Intel B760
Processor Socket	LGA1700 Socket
Max Processors Qty	1
Compatible Processors	(supports 12th and 13th Generation Intel Core / Pentium Gold / Celeron)
Supported RAM
Max Size	96 GB
Technology	DDR5
Bus Clock	5800 MHz (O.C.), 6000 MHz (O.C.), 4800 MHz, 6200 MHz (O.C.), 6400 MHz (O.C.), 6600 MHz (O.C.), 7000 MHz (O.C.), 6800 MHz (O.C.), 7200 MHz (O.C.), 5200 MHz, 5000 MHz, 5600 MHz, 5400 MHz, 7600 MHz (O.C.), 7466 MHz (O.C.)
Supported RAM Integrity Check	Non-ECC
Registered or Buffered	Unbuffered
Features	Dual channel memory architecture, Intel Extreme Memory Profiles (XMP)
Audio
Type	HD Audio (8-channel)
Audio Codec	SupremeFX (S1220A)
Compliant Standards	High Definition Audio, DTS Sound Unbound
LAN
Network Interfaces	2.5 Gigabit Ethernet, Bluetooth 5.3, 802.11a/b/g/n/ac/ax (Wi-Fi 6E)
Expansion / Connectivity
Expansion Slots	1 x CPU 2 x DIMM 288-pin 1 x PCIe 5.0 x16 1 x M.2 socket (2260/2280 M.2 Key M slot) 1 x M.2 socket (2242/2260/2280 M.2 Key M slot)
Storage Interfaces	SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 PCIe 4.0 -connectors: 2 x M.2
RAID Features	Intel Rapid Storage Technology
Interfaces	1 x HDMI 1 x DisplayPort 1 x USB-C 3.2 Gen2x2 1 x USB-C 3.2 Gen 1 3 x USB 3.2 Gen 1 3 x USB 2.0 1 x microphone - mini-jack 1 x audio line-out (center/subwoofer) - mini-jack 1 x audio line-out (rear) - mini-jack 1 x audio line-in - mini-jack 2 x aerial 1 x audio line-out - mini-jack 1 x LAN (2.5Gigabit Ethernet)
Internal Interfaces	1 x USB-C 3.2 Gen 2 - header 2 x USB 3.2 Gen 1 - header 2 x USB 2.0 - header 1 x audio - header 1 x SPDIF out - header
Power Connectors	24-pin main power connector, 8-pin ATX12V connector
Features
BIOS Type	AMI
BIOS Features	UEFI BIOS, ASUS EZ Flash 3, ASUS UEFI BIOS EZ Mode
Sleep / Wake Up	Wake on LAN (WOL), wake on PME
Hardware Features	Jack retasking, ASUS Q-Design, Q-DIMM, ASUS EZ DIY, Q-LED, Q-Slot, ASUS Extreme Engine Digi+, CrashFree BIOS 3, audio jack detect technology, Intel Turbo Boost Technology 2.0, SupremeFX Shielding technology, Preboot eXecution Environment (PXE), 8 Layer PCB, ASUS SafeSlot, ASUS SafeDIMM, ASUS ProCool, Water Pump Header, pre-mounted I/O shield, Intel Turbo Boost Max Technology 3.0, ASUS Aura Sync, 8+1 Phase Power Design, ASUS OptiMem II, DIY Friendly Design, Savitech SV3H712 amplifier, M.2 Q-Latch, 5K Black Metallic Capacitors, Windows 11 compatible, M.2 heatsink backplate
Miscellaneous
Included Accessories	Cable ties, M.2 bracket, STRIX stickers, ROG thank you card, thermal pad for M.2 SSD, ROG key chain, ASUS Wi-Fi moving aerial, 1 x M.2 rubber package, panel cable, 2 x M.2 screw package
Cables Included	2 x Serial ATA cable 1 x USB 2.0 splitter cable 1 x panel cable
Software Included	ROG CPU-Z, ASUS AI Suite III, PC Cleaner, WinRAR, Sonic Studio Virtual Mixer, ROG GameFirst VI, AIDA64 Extreme (60 days trial), ASUS AURA Creator, Sonic Suite Companion, MyAsus, Armoury Crate, Sonic Studio III, Sonic Radar III, ASUS Fan Xpert 4, Norton 360 for Gamers
Width	17 cm
Depth	17 cm
