Technical Specifications
General info Box contents Headset, Leather-feel ear cushion, USB controller – (call
control unit), warning and declarations
Packaging dimensions (WxHxD) 180mm x 228mm x 40mm | 7.08in x 8.97in x 1.57in
Main unit dimensions (WxHxD) 182.12mm x 178.59mm x 39.7mm | 7.16in x 7.02in x 1.56in
Materials used Ear cushion soft audio foam covered in color-matched
leatherette, PC & PC/ABS plastic, PP, TPE, TPU
Headset Weight (stereo variant) 92g | 3.25oz
Weight (stereo) w. in-line link 123g | 4.34oz
USB cable length 1.9m | 6.23ft
LED features and functions Firmware update status, Mute/unmute
Audio Speaker size 30mm
Speaker max input power 30 mW
Speaker frequency range 20Hz - 20000Hz
Speaker bandwidth (music mode) 20Hz - 20000Hz
Speaker bandwidth (speak mode) 170Hz - 6500Hz
Speaker sensitivity 117±3dB at 1mW/1KHz with IEC-318 coupler
Microphone type Electret Condenser (ECM) Uni-Directional Microphone
Microphone sensitivity -42±1dB(0dB=1V/Pa, at 1KHz)
Microphone frequency range Analog 150Hz - 6500Hz |
Microphone bandwidth 150Hz - 6500Hz
User hearing protection PeakStop™
Software & Apps Compatible software and/or apps Jabra+, Direct and Xpress not supported
Fit & Comfort Form factor On-ear headband
Connectivity Connectivity USB-A
Extended info Operating temperature -20°C to 60°C | -4°F to 140°F
Storage temperature -10°C to 65°C | 14°F to 149°F
TECH SHEET
EVOLVE 10
Simple plug & play setup for
maximum productivity
› Compact and minimalist design
that’s as light as a feather
›
Powerful noise-cancelling
microphone ensures you always
sound the part
› 270° rotatable boom arm to
wear on whichever side suits
you
Fully TCO certified and made
from more than 50% recycled
plastic
